INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Product overview
‐8‐
Symbol Instruction Naming instance
C: 4PIN metal plug
D: 7PIN regular aviation plug YD28
E: 4PIN regular aviation plug YD18
N: 4PIN regular aviation plug YD32
S: Copper tube terminal SC
⑥ Plug on drive end
B: Euro 7PIN 20A plug
W: No plug
S: Copper tube terminal SC
⑦ Cable material
0: Regular cable
A: Shielded normal cable
B: Shielded flexible towline cable
F: Flexible towline cable
⑧ Serial no.
00: Standard part
01: Serial no. for non-standard parts
……
1.3.3 Naming of power cable fittings
Symbol Instruction Naming instance
① Product series For internal use by manufacturer
② Power cable ML: Power cable
⑤ Plug on motor end
A: 4PIN plastic plug
B: 4PIN regular aviation plug YD28
C: 4PIN metal plug
D: 7PIN regular aviation plug YD28
E: 4PIN regular aviation plug YD18
N: 4PIN regular aviation plug YD32
S: Copper tube terminal SC
⑥ Plug on drive end
B: Euro 7PIN 20A plug
W: No plug
S: Copper tube terminal SC
1.3.4 Naming of the encoder cables
