SV-DA200 series AC servo drives Faults and solutions
‐174‐
PtP0.73 36
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.75 37
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.77 38
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.79 39
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.81 40
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.83 41
st
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.85 42
nd
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.87 43
rd
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.89 44
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.91 45
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.93 46
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.95 47
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.97 48
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
PtP0.99 49
th
position
Setting range Default Unit Available mode
-(2
31
-1)~(2
31
-1) 0 reference unit P
These parameters are used to set the 01
st
~49
th
position. CMD determines the current position
command mode and P0.37 is invalid.
PtP0.03
Data 32bit Data format DEC
Modbus address 3206,3207 CANopen address 0x2B03,0x00
PtP0.05
Data 32bit Data format DEC
Modbus address 3210,3211 CANopen address 0x2B05,0x00
PtP0.07
Data 32bit Data format DEC
Modbus address 3214,3015 CANopen address 0x2B07,0x00
PtP0.09
Data 32bit Data format DEC
Modbus address 3218,3219 CANopen address 0x2B09,0x00
PtP0.11
Data 32bit Data format DEC
Modbus address 3222,3223 CANopen address 0x2B0B,0x00
