INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Wiring instruction
‐26‐
3.1.3 Cable diameter of main circuit
Small power range (100W~5.5kW) main circuit cable diameter table
Drive model
Recommended cable
diameter (mm
2
)
Connectable cable
diameter (mm
2
)
Terminal
screw
specification
Tightening
torque
(Nm)
L1\L2\L3
UVW
PE L1C\L2C
L1\L2\L3
UVW
(+), B2,
B3, (-)
PE
SV-DA200-0R1-2
0.75 0.75 0.75 0.75~4 0.75~4 0.75~4 M2.5 0.3~0.6
SV-DA200-0R2-2
SV-DA200-0R4-2
SV-DA200-0R7-2
SV-DA200-1R0-2
1.5 1.5 0.75 1.5~4 1.5~4 1.5~4 M2.5 0.3~0.6
SV-DA200-1R5-2
SV-DA200-2R0-2
2.5 2.5 0.75 2.5~4 2.5~4 2.5~4 M4 1.2~1.5
SV-DA200-3R0-2
SV-DA200-4R4-2
SV-DA200-1R0-4
1.5 1.5 0.75 1.5~4 1.5~4 1.5~4 M2.5 0.3~0.6
SV-DA200-1R5-4
SV-DA200-2R0-4
SV-DA200-3R0-4
SV-DA200-4R4-4
2.5 2.5 0.75 2.5~6 2.5~6 2.5~6 M4 1.2~1.5
SV-DA200-5R5-4
Medium power range (7.5kW~22kW) main circuit cable diameter table
Drive model
Recommended
cable diameter
(mm
2
)
Connectable cable diameter
(mm
2
)
Terminal
screw
specification
Tightening
torque
(Nm)
RST
UVW
PE
RST
UVW
(+), PB, (-) PE
SV-DA200-7R5-4 6 6 6~16 6~10 6~10 M5 2~2.5
SV-DA200-011-4 10 10 10~16 10~16 6~16 M5 2~2.5
SV-DA200-015-4 16 16 16~25 16~25 10~16 M6 4~6
SV-DA200-022-4 25 16 25~50 25~50 16~25 M8 9~11
