INSTRUCTIONS - WISEINSIGHT
System Setting - System Tab
Use this to change how to display devices (by text name or by IP
address), how frequently to save data, how frequently to collect data,
set auto login (if checked, it will log in with last-used credentials),
enable/disable run at startup (if checked will run program
automatically at PC startup), enable/disable time server (if checked,
it will open the time server and the network adapter will adjust the
system time automatically), enable/disable the audible voice alarm
(if checked an audible voice will play through PC speakers when an
alarm is triggered), enable/disable the dialog alarm (if checked, a
screen alert pop-up appears if an alarm is triggered).
1.
WiseInsight - System Menu
System Setting - Protocol Tab
Use this menu (second tab in system setting menu option) to change
the SNMP trap protocols. The default values are:
SNMP Version: V2
Retry: 3 Timeout(s): 3
SNMP Port: 161 Trap Port: 162
Community: Public
In WiseInsight, the configuration of SNMP protocol should be
consistent with the protocol of the network adapter, which ensures
the communication with the SNMP card is normal.
2.
The following instructions will go through options available under the “System” menu. These settings
can only be adjusted by a user who has read/write access.
20
System Setting - Device Tab
Use this menu (third tab in system setting menu option) to change
what live data is shown on the main screen tabs. EG: If the UPS SNMP
cards do not have an environmental monitoring device, you can
uncheck all boxes in the “Environment” sub-tab. When unchecked,
they will not show any data or values in the Environment tab when
viewing data of a UPS.
3.
