6
VIN+
DC Power Input. See power input range below.
This input is protected via 5A fuse.
7
GND
8
VIN+
DC Power Input. See power input range below.
This input is protected via 5A fuse.
9
GND
10
VRTC
DC Power Input for RTC.
11
N/C
12
N/C
13
GND
14
Heater Out
DC Power Output for HEATER control.
Optional, please consult IONODES for more
info. (5V)
15
GND
16
FAN Out
DC Power Output for FAN control.
Optional, please consult IONODES for more
info. (5V)
Power Input Range
The power input range on the ATOMAS-MINI-LVDS device is 7VDC to 12VDC.
The power input range on the ATOMAS-MINI-YUV device is 7VDC to 14VDC.
Note: IONODES has an optional PoE module (power-over-Ethernet) which can be used to
add PoE support for your ATOMAS-MINI design. This module provides direct con-
nection via a supplied cable. For more information on this module, please contact
us.
VRTC
VRTC is provided in order to allow for optional integration of an external battery source (1.3V to
5.5V) for feeding the module’s realtime clock (RTC). VRTC is only required to keep the
date/time when the main power supply is not connected. All other data is saved in persistent
FLASH memory.
Note: VRTC is not a mandatory signal to operate the ATOMAS-MINI.
