J1 – Micro SD Socket
In order to use the micro SD functionalities with the ATOMAS-MINI, make sure to use a 2GB to
64GB micro SD of class 6 or above. You must also make sure the card is formatted in FAT32 or
EXT3.
J2 – 10 Pin Micro SD / SD Connector
Pin No.
Name
Level
1
Data Bit 1
2
Data Bit 0
3
GND
4
Clock
5
Power
2.7V – 3.6V DC
6
Command Line
7
Data Bit 3
8
Data Bit 2
9
Card Detect
10
Write Protect
Not Connected
Note: This connector is designed to mate with connector J4 of the ATOMAS-MINI encoder
module. Pinout is inverted to keep the harness cable straight.
