J14 – LVDS Video Interface
Kel / USL00-30L
Pin No.
Name
Comments
1
LVDS DATA3 +
2
LVDS DATA3 -
3
LVDS CLK +
4
LVDS CLK -
5
LVDS DATA2 +
6
LVDS DATA2 -
7
LVDS DATA1 +
8
LVDS DATA1 -
9
LVDS DATA0 +
10
LVDS DATA0-
11
GND
12
CAM UART TX
Connects to camera’s TxD.
CMOS 5V
Low: Max 0.1V
High: Min 4.4V
13
CAM UART RX
Connects to camera’s RxD.
CMOS 5V
Low: Max 1.0V
High: Min 2.3V
14
DC OUT
7V to 12V DC.
Sourced directly from provided VIN.
15
DC OUT
7V to 12V DC.
Sourced directly from provided VIN.
16
DC OUT
7V to 12V DC.
Sourced directly from provided VIN.
17
DC OUT
7V to 12V DC.
Sourced directly from provided VIN.
18
DC OUT
7V to 12V DC.
Sourced directly from provided VIN.
19
GND
