Connector Part Numbers
x ATOMAS-MINI-LVDS / Module
o J1 – SAMTEC / TFC-115-32-F-D
o J2 – TE Connectivity / 1-1734839-0
o J3 – MOLEX / 5041891670
o J7 – SAMTEC / TFC-110-32-F-D
o J8 – SAMTEC / CLP-103-02-G-D
o J14 – Kel / USL00-30L
x ATOMAS-MINI-YUV / Module
o J1 – SAMTEC / TFC-115-32-F-D
o J2 – TE Connectivity / 1-1734839-0
o J3 – MOLEX / 5041891670
o J4 – AVX / 04-6296-045-931-846+
o J7 – SAMTEC / TFC-110-32-F-D
J1 – Audio & I/O Signals
SAMTEC / TFC-115-32-F-D
Pin No.
Name
Comments
1
UART0 TX
Serial Port TX – TTL Level 3.3V or 5V.
Unprotected, please provide appropriate
protection on external source.
2
DEBUG TX
For internal purposes only. DO NOT USE.
3
UART0 RX
Serial Port RX – TTL Level 3.3V or 5V.
Unprotected, please provide appropriate
protection on external source.
4
DEBUG RX
For internal purposes only. DO NOT USE.
5
AUDIO LINE OUT RIGHT
6
AUDIO LINE OUT LEFT
7
GND
8
AUDIO COMMON
9
AUDIO LINE IN RIGHT
