J7 – Network & Power Outputs
SAMTEC / TFC-110-32-F-D
Pin No.
Name
Level
1
10/100 LAN TX +
Connects directly to RJ45 or network wiring.
2
10/100 LAN RX -
Connects directly to RJ45 or network wiring.
3
10/100 LAN TX -
Connects directly to RJ45 or network wiring.
4
10/100 LAN RX +
Connects directly to RJ45 or network wiring.
5
N/C
6
N/C
7
10/100 LAN LED2
Connects directly to RJ45 or network wiring.
8
10/100 LAN LED1
Connects directly to RJ45 or network wiring.
9
5V Out
5V DC Power Output (max. 1.5A)
10
3.3V Out
3.3V DC Power Output (max. 350mA)
11
FAN
DC Power Output for FAN control.
Optional, please consult IONODES for more info. (5V)
12
HEATER
DC Power Output for HEATER control.
Optional, please consult IONODES for more info. (5V)
13
GND
14
GND
15
VRTC
DC Power Input for RTC.
16
VIN
DC Power Input. See power input range in section 0.
This input is not protected, use J3 VIN if possible.
17
GND
18
VIN
DC Power Input. See power input range in section 0.
This input is not protected, use J3 VIN if possible.
19
GND
20
GND
Warning: VIN power input on connector J7 is NOT protected. We recommend using VIN power
input found on connector J3 which has 5A fuse protection. Should you choose to use J7
VIN, please ensure proper fuse protection on your VIN prior to connecting to the
ATOMAS-MINI.
