IONODES ATOMAS-MINI - J4 - Parallel Video Interface

Page 16 of 71
J4 – Parallel Video Interface
AVX / 04-6296-045-931-846+
Pin No.
Name
Comments
1
GND
2
GND
3
SCL
I2C Serial Bus Clock
4
SDA
I2C Serial Bus Data I/O
5
XRST
System Reset
6
GND
7
N/A
DO NOT CONNECT.
8
N/A
DO NOT CONNECT.
9
N/A
DO NOT CONNECT.
10
N/A
DO NOT CONNECT.
11
N/A
DO NOT CONNECT.
12
N/A
DO NOT CONNECT.
13
GND
14
VD
Digital Video V-Active Signal
15
HD
Digital Video H-Active Signal
16
Y0
Digital Video Data (Luminance Parallel Data0)
17
Y1
Digital Video Data (Luminance Parallel Data1)
18
Y2
Digital Video Data (Luminance Parallel Data2)
19
Y3
Digital Video Data (Luminance Parallel Data3)
20
Y4
Digital Video Data (Luminance Parallel Data4)
21
Y5
Digital Video Data (Luminance Parallel Data5)
22
Y6
Digital Video Data (Luminance Parallel Data6)
23
Y7
Digital Video Data (Luminance Parallel Data7)
24
DCLK
Digital Video Clock
25
C0
Digital Video Data (Chroma Parallel Data 0)
26
C1
Digital Video Data (Chroma Parallel Data 1)
27
C2
Digital Video Data (Chroma Parallel Data 2)
28
C3
Digital Video Data (Chroma Parallel Data 3)
29
C4
Digital Video Data (Chroma Parallel Data 4)
30
C5
Digital Video Data (Chroma Parallel Data 5)
