ATOMAS-MINI-SDIO
The ATOMAS-MINI-SDIO breakout card is an optional module provided by IONODES which
provides microSD storage support to your ATOMAS-MINI module.
The ATOMAS-MINI-SDIO module is provided as part of the ATOMAS-MINI-SDIO-KIT part
number which also includes a cable required to connect the ATOMAS-MINI-SDIO to the
ATOMAS-MINI module.
Pinout Description
Figure 3 - Top Side
Connector Part Numbers
x J1 – MOLEX 502570-0893
x J2 – TE CONNECTIVITY 1-1734839-0
