MEZ DRY IN Signals
The ATOMAS-MINI provides two (2) input pin signals, MEZ DRY IN1 and MEZ DRY IN2, for
eventing purposes. To trigger an input pin (closed stated), you must connect the appropriate
MEZ DRY IN signal with the provided GND located on connector J1. To set the open state,
leave the input floating.
J2 - 10 Pin Micro SD / SD Connector
TE CONNECTIVITY 1-1734839-0
Pin No.
Name
Level
1
Write Protect
2
Card Detect
3
Data Bit 2
4
Data Bit 3
5
Command Line
6
Power
2.7V – 3.6V DC
7
Clock
8
GND
9
Data Bit 0
10
Data Bit 1
Note: In order to use the micro SD / SD functionalities, make sure to use a 2GB to 64GB
micro SD / SD card of class 6 or above. You must also make sure the card is for-
matted in FAT32 or EXT3.
J3 – Power Inputs
MOLEX / 5041891670
Pin No.
Name
Level
1
GND
2
VIN+
DC Power Input. See power input range below.
This input is protected via 5A fuse.
3
GND
4
VIN+
DC Power Input. See power input range below.
This input is protected via 5A fuse.
5
GND
