Warning: Please do not use VIN and VRTC signals on both J7 and J3 connectors simultaneously;
please design according to use of only one of these two methods to provide DC power
to the ATOMAS-MINI.
Network
J7 provides standard 4-wire network connectivity. You only need
4 wires for 10/100 Base-T network connection, please connect
the appropriate network connection pins to your RJ45 connector
or wiring. Network status LED pins are also accessible if needed.
Note: Magnetics are included on the ATOMAS-MINI, J7 can
therefore be connected directly to network switching
equipment.
J8 – Internal Port
Note: For internal purposes only. DO NOT USE.
Note: Available on ATOMAS-MINI-LVDS only.
