31
C6
Digital Video Data (Chroma Parallel Data 6)
32
C7
Digital Video Data (Chroma Parallel Data 7)
33
TRIGB
Mode Transition Signal
34
STRB
Camera Strobe Signal
35
GND
36
GND
37
VDD_18
Power Supply (1.8V)
38
VDD_12
Power Supply (1.2V)
39
VDD_12
Power Supply (1.2V)
40
VDD_12
Power Supply (1.2V)
41
VDD_33
Power Supply (3.3V)
42
VDD_33
Power Supply (3.3V)
43
VDD_33
Power Supply (3.3V)
44
GND
45
GND
Note: Available on ATOMAS-MINI-YUV only.
Note: The HD sensor connector has been designed to be directly compatible with SONY’s
FFC ribbon cables used with their FCB Micro Series cameras.
Note: The following cable is recommended for connectivity between connector J3 and the
SONY FCB-MICRO cameras:
MOLEX P/N: 0150150245: CABLE FLAT FLEX 45POS .3MM 2"
