YLR-SERIES USER GUIDE
IPG PHOTONICS | COMPUTER INTERFACE / COMMANDS
49
C
C
O
O
D
D
E
E
D
D
E
E
S
S
C
C
R
R
I
I
P
P
T
T
I
I
O
O
N
N
E
E
X
X
A
A
M
M
P
P
L
L
E
E
S
S
STA
Read device status – The status is reported as a bit-encoded
32-bit word. Undefined bits or bits defined as “Reserved” can
be in any state and should be ignored. Each of the bits have
the following meaning:
Bit 0
-
Reserved
Bit 1
-
0
=
Normal operation
-
1
=
Overheat
Bit 2
-
0
=
Emission Off
-
1
=
Emission On or starting
Bit 3
-
0
=
Back Reflection OK
-
1
=
High Back Reflection Level
Bit 4
-
0
=
External Control Mode Disabled
-
1
=
External Control Mode Enabled
Bit 5
-
Reserved
Bit 6
-
0
=
Normal operation
-
1
=
Module Disconnected
Bit 7
-
Reserved
Bit 8
-
0
=
Aiming Beam OFF
-
1
=
Aiming Beam ON
Bit 9
1
-
0
=
Normal operation
-
1
=
Pulse too Short
Bit 10
1
-
0
=
CW Mode
-
1
=
Pulsed Mode
Bit 11
-
0
=
Power Supply On
-
1
=
Power Supply Off
Bit 12
-
0
=
Modulation Disabled
-
1
=
Modulation Enabled
Bit 13
-
Reserved
Bit 14
-
Reserved
Bit 15
-
0
=
Emission is out of 3 second start-up state
-
1
=
Emission is in 3 second start-up state
(in ON position of the keyswitch only)
Bit 16
-
0
=
Gate Mode Disabled
-
1
=
Gate Mode Enabled
Bit 17
1
-
0
=
Normal Operation
-
1
=
High Pulse Energy
Bit 18
-
0
=
Hardware Emission Control Disabled
-
1
=
Hardware Emission Control Enabled
Bit 19
-
0
=
Normal operation
-
1
=
Power Supply Failure
Bit 20
-
0
=
Front Panel Display is Unlocked
-
1
=
Front Panel Display is Locked
Bit 21
-
0
=
Keyswitch in ON position
-
1
=
Keyswitch in REM position
Sent: “STA”
Response: “STA: 4100”
This translates to the following:
4100 = 0x1004, so bits 2 and
12 are set. This means that
emission is on and modulation
is enabled.
1
QCW MODELS ONLY
