Chapter 1 BEFORE USE

1.7 REMOVING & REPLACING OF WEIGH PLATTER
1.7.1 REMOVING THE WEIGH PLATTER
When removing the weigh platter from the main body, lift the front side to pull out the two pins from
the two rubber platter holders and remove the platter by pulling it to disengage the two hooks at the
rear side of the platter.
1.7.2 REPLACING THE WEIGH PLATTER
When replacing the weigh platter onto the main body, engage the two hooks at the rear side of the
platter and lower the platter so that the two pins on the bottom of the platter are inserted into holes of
the rubber platter holders.
UNI-7 User’s Manual 1-9
