iSMA MINI Series - Hand Control Status of Triac Outputs (30015)

MINI and MIX Series I/O modules/Modbus
version 1.3 www.gc5.pl Page 36 / 73
Register
value
Description
1 (default)
Digital Output
2
PWM 1Hz
3
PWM 10Hz
4
Not supported
5
PWM 0.1 HZ
6
PWM 0.01Hz
Table 29 TO type settings
Hand control status of Triac Outputs (30015)
This register is available only for the modules with manual control of outputs.
No of bit in
register
Description
0,1
Hand status of outputs 1
2,3
Hand status of outputs 2
4,5
Hand status of outputs 3
6,7
Hand status of outputs 4
Table 30 TO Hand status bits
Value of Hand
status
Status
Description
0
AUTO
2
HAND OUT = 0
3
HAND OUT = 1
Table 31 TO Hand status value
