3.11 Special application modes for 4I4O-H, 4I4O-H-IP, 4U4O-H and 4U4O-
H-IP
In 4I4O-H, 4I4O-H-IP, 4U4O-H, 4U4O-H-IP modules simple applications have been built which
can be used to control building devices. The applications make logic between signal from
Digital Input and control Digital Output state. Relation between Inputs and Outputs is shown
in the table below and it cannot be changed.
Digital Input
Digital Output
DI1
DO1
DI2
DO2
DI3
DO3
DI4
DO4
Table 32 Built in application relation between input and output
The Digital Inputs in modules type 4I4O-H, 4I4O-H-IP, 4U4O-H, 4U4O-H-IP can be set to work
in different modes. There are dedicated registers for operation mode (40176, 40180, 40184,
40188), time parameters (40177, 40181, 40185, 40189), setpoints for heating/cooling
modes (40178, 40182, 40186, 40190 4U4O-H and 4U4O-H-IP only) and for differential value
in heating/cooling modes (40179, 40183, 40187, 40191 4U4O-H and 4U4O-H-IP only).
Register
Description
40176
DI1 OPERATION MODE
40177
DI1 TIME VALUE
40178
DI1 SETPOINT
(4U4O-H and 4U4O-H-IP only)
40179
DI1 DIFFERENTIAL
(4U4O-H and 4U4O-H-IP only)
40180
DI2 OPERATION MODE
40181
DI2 TIME VALUE
40182
DI2 SETPOINT
(4U4O-H and 4U4O-H-IP only)
40183
DI2 DIFFERENTIAL
(4U4O-H and 4U4O-H-IP only)
40184
DI3 OPERATION MODE
40185
DI3 TIME VALUE
40186
DI3 SETPOINT
(4U4O-H and 4U4O-H-IP only)
40187
DI3 DIFFERENTIAL
(4U4O-H and 4U4O-H-IP only)
40188
DI4 OPERATION MODE
40189
DI4 TIME VALUE
