iSMA MINI Series - 1.4 Module Summary and Specifications

MINI and MIX Series I/O modules/Modbus
version 1.3 www.gc5.pl Page 9 / 73
1x Fast Ethernet
IP Interface
Baud rate
10/100 Mb/s
USB
USB
Mini USB 2.0
Ingress protection
IP
IP40
Temperature
Storage
-40˚C to +85˚C
Operating
-10˚C to +50˚C
Humidity
Relative
5% to 95%
Connectors
Type
Removable
Maximum cable size
2.5 mm2
Dimension
MIX18, MIX18-IP
Width
110 mm
Length
88 mm
Height
62 mm
MIX38, MIX38-IP
Width
110 mm
Length
160 mm
Height
62 mm
MINI Series
Width
110 mm
Length
37 mm
Height
62 mm
Table 2 Technical specification
1.4 Summary table for all modules
Module
type
UI
DI
AO
DO
TO
Modbu
s
RS485
Modbus
TCP/IP
BACnet
MSTP
BA
Cn
et
IP
4I4O-H
4
4
✓
✓
4I4O-H-IP
4
4
✓
✓
✓
4O-H
4 (NC/NO-8A)
✓
✓
4O-H-IP
4 (NC/NO-8A)
✓
✓
✓
4U4A-H
4
4
✓
✓
4U4A-H-IP
4
4
✓
✓
✓
4U4O-H
4
4
✓
✓
4U4O-H-IP
4
4
✓
✓
✓
8I
8
✓
✓
8I-IP
8
✓
✓
✓
8U
8
✓
✓
8U-IP
8
✓
✓
✓
