1.3 Technical specifications
Power supply
Voltage
24 V AC/DC ± 20%
Power consumption
Module type
@ 24 VDC
@ 24 VAC
8I
0.4 W
0.6 VA
8I-IP
1.4 W
2.1 VA
8U
0.5 W
0.8 VA
8U-IP
1.5 W
2.3 VA
4I4O-H
1.2 W
1.8 VA
4I4O-H-IP
2.2 W
3.3 VA
4U4O-H
1.2 W
1.8 VA
4U4O-H-IP
2.2 W
3.3 VA
4U4A-H
2.2 W
3.3 VA
4U4A-H-IP
3.2 W
4.8 VA
4O-H
1.6 W
2.4 VA
4O-H-IP
2.6 W
3.9 VA
4TO-H
1.0 W
1.5 VA
4TO-H-IP
2.0 W
3.0 VA
MIX18
3.0 W
4.5 VA
MIX18-IP
4.4 W
6.6 VA
MIX38
5.0 W
7.5 VA
MIX38-IP
7.4 W
11.1 VA
Universal Inputs
Temperature input
• Measurement with attached RTDs
• accuracy ±0,1˚C
• For sensor Pt1000 and Ni1000 use 16-bit
resolution
Voltage input
• Voltage measurement from 0 - 10 V
• Input impedance 100 kΩ
• Measurement accuracy ±0,1%
• Measurement resolution 3 mV@12-bit and 1
mV@ 16-bit
Current input
• Current measurement 0 - 20 mA
• Required external resistor 200 Ω
• Measurement accuracy ±1,1%
• Measurement resolution 15 µA @ 12-bit and 5 µA
@ 16-bit
Resistive input
• Measurement of resistance from 0 to 1000 kΩ
• Measurement resolution for 20 kΩ load 20 Ω@12-
bit and 1 Ω@16-bit
• Measurement resolution for PT1000 and NI1000
0,1Ω@16bit
