Formula for the current measurements:
where: U – register value,
500 – value of attached resistor
Temperature is expressed in Celsius
degrees * 10
For a result, divide the registry value by
10:
Selection of the type sensor is done
using UNIVERSAL INPUT
CONFIGURATION register from 40151
to 40158 for each input separately
