iSMA MINI Series - 6.6 Registers 40168-40183

MINI and MIX Series I/O modules/Modbus
version 1.3 www.gc5.pl Page 60 / 73
Modbus
Addr
Dec
Addr
Hex
Addr
Register name
Access
Description
with 12-bit resolution.
40168
167
0xA7
ANALOG OUTPUT
CONFIGURATION 1
Read &
Write
Memory
Configuring the mode of Analog Output
according to the following table:
Value
Description
0 (default)
Voltage output 0-10V
1
PWM 1Hz
2
PWM 10Hz
3
PWM 100Hz
4
PWM 0.1Hz
5
PWM 0.01Hz
40169
168
0xA8
ANALOG OUTPUT
CONFIGURATION 2
Read &
Write
Memory
40170
169
0xA9
ANALOG OUTPUT
CONFIGURATION 3
Read &
Write
Memory
40171
170
0xAA
ANALOG OUTPUT
CONFIGURATION 4
Read &
Write
Memory
40172
171
0xAB
ANALOG OUTPUT
CONFIGURATION 5
Read &
Write
Memory
40173
172
0xAC
ANALOG OUTPUT
CONFIGURATION 6
Read &
Write
Memory
40176
175
0xAF
DIGITAL INPUT 1
CONFIGURATIO MODE
Read &
Write
Memory
DIGITAL INPUT CONFIGURATIO MODE
table:
Value
Description
0
Ordinary IO
1
Monostable Relay
2
Bistable Relay
3
Time Relay
DIGITAL INPUT TIME VALUE in [ms] or
in [s] – depends on mode selection
SETPOINT in
o
C multiplied by 10
Default value = 0
40177
176
0xB0
DIGITAL INPUT 1
TIME VALUE
Read &
Write
Memory
40178
177
0xB1
DIGITAL INPUT 1
SETPOINT
Read &
Write
Memory
40179
178
0xB2
DIGITAL INPUT 1
DIFFERENTIAL
Read &
Write
Memory
40180
179
0xB3
DIGITAL INPUT 2
CONFIGURATIO MODE
Read &
Write
Memory
40181
180
0xB4
DIGITAL INPUT 2
TIME VALUE
Read &
Write
Memory
40182
181
0xB5
DIGITAL INPUT 2
SETPOINT
Read &
Write
Memory
40183
182
0xB6
DIGITAL INPUT 2
DIFFERENTIAL
Read &
Write
Memory
