4-20
CONTROLS AND INSTRUMENTS
Warning and Indicator Lights Layout
Warning lights
When the power mode is switched to "ON" (models with passive entry and start
system) or the starter switch is turned to the "ON" position (models without passive
entry and start system) for the operation check, the warning light comes on. The light
turns off within a few seconds or when the engine is started.
If the light does not come on or does not turn off, there may be a problem with the
system. Have the vehicle inspected at the nearest Isuzu Dealer.
Symbol
Name
Operation
check
Reference
page
Front seat belt warning light 4-50
SRS airbag warning light 4-53
Brake system warning light 4-54
Parking brake warning light ― 4-55
ABS warning light 4-56
ESC warning light 4-57
