8-2
MAIN DATA
Main Data and Specifications
Engine
RZ4E Engine Model
Specifications
Water-cooled, overhead camshaft, direct injection engine with an inter-cooled turbocharger
Compression ratio (to 1) 16.5
Displacement cc (cu. in) 1,898 (115.8)
Firing order 1-3-4-2
Fuel injection timing Electronic control
Valve clearance (Between cam and roller) No adjustments needed
Idling speed r/min 725 - 775
Belt tension Accessory belt: Automatic adjust
Oil filter Replaceable element type
Engine oil capacity [Reference value]
liters (US gal./Imp gal.)
When changing oil and filter:
6.6 (1.74/1.45)
Engine coolant capacity [Reference value]
liters (US gal./Imp gal.) (M/T) 10.7 (2.83/2.35), (A/T) 11.1 (2.93/2.44)
Preheating system Glow plugs
5108428_sec08_MAIN DATA.indd 2 2020/11/20 15:36:34
