4-48
CONTROLS AND
INSTRUMENTS
Driving support settings
The items that can be changed are as follows.
Display indication
Page
T
raffic sign
recognition
T
raffic sign display
Enable
4-288
Disable
Speed warning
Visual and audible
4-288
Visual only
Off
W
arning threshold
2 km/h (1 MPH)
4-288
5 km/h (3 MPH)
10 km/h (6 MPH)
Automatic high beam
Mode
Enable
4-336
Disable
Speed limiter
Mode
Intelligent
4-296
Manual
4-292
Automatic
emergency braking
Brake and warning intervention
Enable
4-248
Disable
W
arning sensitivity
Far
4-247
Normal
Near
Lane support settings
Lane departure prevention
Assist and warning
4-310
W
arning only
4-310
Off
4-301
4-310
Emergency lane keeping
Enable
4-320
Disable
Attention assist
Enable
4-332
Disable
Lane departure
warning
Lane departure warning
Enable
4-301
Disable
Blind spot monitor
Warning
Enable
4-198
Disable
Rear cross traffic
alert
W
arning
Enable
4-207
Disable
