8-9
MAIN DATA
Wheel
Wheel alignment : Toe-in mm (in) 0 (0)
: Camber (degree) 0°
: Caster (degree) 3°20´
: King pin (degree) 12°30´
Service brakes
Brake pedal free play Refer to page 6-62
Brake pedal height Refer to page 6-62
Clearance between the brake pedal and the floor Refer to page 6-62
Parking brake
Lever effective stroke
(Under pull force of approximately 294 N (30 kgf/
66 lb)) 6 - 9 notches
Electrical system
Battery type Single battery: EN: 385LN3-ISS
EN: 400LN4-ISS
Dual batteries: EN: 385LN3-ISS × 2
Starter volt-kw 12 - 1.6
Generator volt/amp. 12/120
5108428_sec08_MAIN DATA.indd 9 2020/11/20 15:36:34
