System Commands

Chapter5 Harmonic Commands

In commands of harmonics measurement, the range of values for parameter

“value” is zero to fifty. 0 corresponds to DC, 1 corresponds to fundamental

harmonic and 2-50 corresponds to harmonics. The instrument interface should

be under the harmonics function while using the harmonics command to

measure.

MEASure[:SCALar]:HARMonics?

FETCh[:SCALar]:HARMonics?

This command is used to read the harmonic of a phase.

Command syntax

MEASure[:SCALar]:HARMonics? <A|B|C>,<U|I|ALL>

FETCh[:SCALar]:HARMonics? <A|B|C>,<U|I|ALL>

Arguments

<A|B|C>

<U|I|ALL>

Returns

<float>

MEASure[:SCALar]:VOLTage:HARMonics[:AMPLitude]

FETCh[:SCALar]:VOLTage:HARMonics[:AMPLitude]?

This command is used to read the real-time measured voltage amplitude of a

harmonic.

Command syntax

MEASure[:SCALar]:VOLTage:HARMonics[:AMPLitude]?

<A|B|C>,<FUNDamental|TOTal| ALL|value>

FETCh[:SCALar]:VOLTage:HARMonics[:AMPLitude]?<A|B|C>,FUNDamental|T

OTal|ALL| order

Arguments

<A|B|C>,

<FUNDamental|TOTal|ALL|value>
