Basic Operation
2. Set the value of Sample Period and press [Enter].
3. Set the value of Duration and press [Enter].
4. Set the value of Source and press [Enter].
5. Set the value of Data Type and press [Enter].
At this point, the VFD screen returns to the main interface of the system.
Select the Trigger Method
See the steps in the 5.8 Select Trigger Source (Trig Source) section to set how
the data logging is triggered.
This setting result is only valid for data recording function. When List function
is used, the method for triggering the running of List files needs to be addi-
tionally set (by default, triggered by the panel).
Start Data Logging
Before this operation, make sure to connect the USB memory device
to the memory port on the front panel (The USB interface on the rear
panel can only be used for connecting the PC) so that the recorded
data can be stored in the external storage device. Otherwise, the Data
Recording function is not available for usage.
• Manual
Press the composite button [Shift] + [On/Off] (Trigger) on the front panel to
trigger.
• Bus
Triggered by the SCPI instruction, for example, when the instrument re-
ceives the trigger command *TRG, a trigger operation is performed.
• External
Connect to pin 4 of the digital I/O interface (P-IO) and set pin 4 to Ext-Trig→-
Trig-In→Dlog to trigger.
For details, see 5.11.4 IO–4. Ext-Trig, Not-Invert.
