Function and Features
Copyright © ITECH Electronic Co., Ltd. 30
Low
Set low voltage value.
Point 1= 0.00V
High
Set high voltage value.
Point 2= 120.00V
Time C
Measure current rise/fall time.
Low
Set low current value.
Point 1= 0.00A
High
Set high current value.
Point 2= 5.00A
FILTER
Smoothing function.
Average Count=2^(2~16)
Set of average count.
CR-LED
CR LED MODE
Analog LED lamp function (under CR mode).
On
Start CR-LED function.
Off
Stop CR-LED function.
Remote-Sense
REMOTE SENSE STATE
Remote sense compensation
measurement.
On
Start remote sense
compensation function
Off
Stop remote sense
compensation function
Ext-Program
EXTNAL PROGRAM
External analog quantity
function.
On
Start external 0-10 V analog quantity control
function.
Off
Stop external 0-10 V analog quantity control
function.
3.8 Triggering function
Triggering function is necessary to operate dynamic pulse output and list output.
There are five triggering methods to trigger the tested instrument. Optional
triggering sources of triggering function of electronic load comprise:
 Key ([Trigger] key) trigger: when key trigger is valid, press [Shift]
+ .(Trigger) key and the load will trigger an operation.
 External trigger signal (TTL): TRIG on the rear board is the triggering
input terminal. When external trigger signal method is effective, after applying a
low pulse (> 10 us), the load will trigger an operation.
 Bus trigger: when the bus trigger is valid, after the load receives a trigger
command (GET or * TRG) from GPIB port, the load will trigger an operation.
 Timing trigger: when the timing trigger is valid, the load will automatically
trigger an operation at intervals.
 Trigger holding: when trigger holding is valid, only when the load receives
trigger command (TRIG:IMM), the load will trigger an operation.
Select the triggering sources as follows:
Operation steps
1. Press [Shift] + 8(System) to enter system menu setting screen.
Initialize Power-ON Buzzer
2. Press to move to the Trigger and press [Enter] to enter
