3. Operate key and select high rate and low rate. Move to the
High-Rate and press [Enter] key.
TRANSITION
High-Rate Low-Rate
4. Set ascending slope and press [Enter] key.
TRANSITION
Rise up=2.000A/uS
5. Set descending slope and press [Enter] key.
TRANSITION
Rise down=2.000A/uS
6. Set A value and press [Enter] key.
TRANSITION
Level A=1A
7. Set B value and press [Enter] key.
TRANSITION
Level B=2A
8. Set frequency value and press [Enter] key.
TRANSITION
Frequency=50Hz(0.01-25000Hz)
9. Set duty ratio and press [Enter] key.
TRANSITION
Duty=98%(0.1%-99.9%)
10. Start dynamic test and operate key. Move to On and press
[Enter] key.
TRANSITION
On Off
11. Enter the dynamic test mode.
10.0000V 0.0000A
0.00W 0 TRAN
12. Press [On/Off] key to open input and press [Shift] + . (Trigger).
The load will continuously switch between A and B value. Time of
operations is shown at bottom right.
13. Press [CC]/ [CV]/ [CR]/ [CW] key or any composite function key to exit
dynamic test function. Repeat Steps 1-12 to continue parameter setting
and operation of dynamic test.
3.9.2 Pulse mode
Under pulse mode, after enabling dynamic test operation, the load will switch to
A value after receiving of a trigger signal. Then the load will switch back to B
value and be constant at B value after maintaining A for pulse width time.
