If the above method is for editing auto test step (as mentioned below), constant power
range can also be set.
3.3 Input control function
Control input switch of the electronic load by pressing [On/Off] key on the front
board. If [On/Off] lamp is on, the input is on; and if [On/Off] lamp is off, the VFD
Off is on and the input is off. When the electronic load is on, the VFD working
status indicator is OFF.
3.4 Keyboard locking function
Press the composite key [Shift] + [On/Off] (Lock) to lock the instrument board
key, and the VFD displays *. Under other function statuses, except [On/Off] key
and [Shift] + 7 (Info), other keys are disabled. Press this composite key to
cancel locking.
3.5 Short-circuit analog function
The load can analog a short circuited circuit at input terminal. Under board
operation, press the [Shift] + 1(Short) key to switch short circuit status. The
short circuit status does not influence existing setting value. When the short
circuit operation is switched back to OFF status, the load returns back to
original setting status.
Actual current value consumed by load at short circuit depends on the existing
working mode of load and current range. Under CC, CP and CR modes,
maximum short-circuit current is 110% of current range. Under CV mode, short
circuit current is equivalent to that constant voltage value of load is 0 V.
3.6 System menu function (System)
Press [Shift] + 8(System) to enter system menu setting.
Reset
INITIALIZE SYSTEM?
NO
Keep existing configurations.
YES
Recover all configurations to factory set
values.
Power-on
POWER-ON PARAMENT
RST(default)
Set the input status of load at powering on
as "status as delivered".
SAV0
Set the input status of load at powering on
as SAVE 0 value.
Buzzer
BUZZER STATE
Set the buzzer status.
On(default)
Set the buzzer as ON status.
Off
Set the buzzer as OFF status.
Knob
LOAD ON KNOB MODE
Set the pulse knob.
Update(default)
Real-time update.
Old
No update (Recover to original value at
ON/OFF).
Trigger
TRIGGER SOURCE
Set triggering mode.
Manual(Def)
Manual trigger.
External
External signal trigger mode.
Hold
Trig: IMM valid.
Bus
GPIB bus trigger mode.
Timer
Timer trigger mode.
