CHASSIS MODIFICATIONS
2-25
DAILY 4x4
Print 603.93.761 Base - May 2007
Installing a Supplementary Axle
As far as sliding shafts are co ncerned, length”LG” is measured between the universal joint centres, with the sliding stub in t h e
intermediate position. Always check both sections LG and LZ.
The maximum working revs c an be obtained u sing t he formula below:
n
G
=
n
max
i
G
n
G
= maximum number of transmission shaft revs (r.p.m.)
n
max
= maximum number of engine revs (r.p.m.), refer to Table 2.12
i
G
= gearbox ratio in the fastest gear, refer to Table 2.13
Table 2.12 - Maximum number of engine revs
Engine Engine code (1) n
max
.18 F1CE0481H*C 3500
(1) = Check the engine code on the engine rating plate
Table 2.13 - Gearbox ratio with the fastest gear
Gearbox i
G
6S400 - 2840.6 0.8
Example of calculation of the maximum obtainable transmission length
Let us consider a 35C13 equipped with a ZF S5-200 gearbox. Let us assume you wish to use a propeller shaft LZ
with an outer diameter of 76.2 mm.
From the data below:
1. n
max
= 3600 rpm
2. i
G
=0.8
the following will be obtained:
n
G
= 3600 / (0.8) = 4500 rpm
This value c o rresponds to a maximum obtainable length of 1.400 mm.
The universal joints on the same shaft should not be rotated.
