10
– Vacuum pump connection
Connect the vacuum pump plug (26) with the vacuum pump socket (25).
We recommend using a vacuum pump from Ivoclar Vivadent, since these
pumps are especially coordinated with the furnace. If other pumps are
used, always observe and do not exceed the maximum power
consumption specified on the rating plate at the rear of the device.
Connect the vacuum hose (30) with the vacuum hose connection (29).
Do not shorten the vacuum hose!
The minimum length of the vacuum hose is 1.6 m.
– Connect the power cord with the wall socket.
– Put the On/Off switch (34) at the rear of the furnace on position I.
Please note that the furnace may require a certain acclimation
time (up to four hours) after having been transported. This is
particularly true if the furnace was exposed to substantial
temperature changes (water condensation). Switch the furnace on only after the acclimation time.
Basic settings upon initial start-up
Upon the initial start-up of the new furnace, a number of basic settings are required. These settings are saved and can be
edited in the settings menu at a later time.
Step 1:
Select the language
The first setting is the language selection. The touch buttons (display keys) can be operated by tapping the display.
Step 1 Step 2 Step 3
Select the desired language using the [Arrow up/down] buttons. Confirm the entry with the green button. By pressing
the [Continue] button, you will reach the next entry screen.
Step 2:
Select the temperature unit
Select the desired temperature unit.
By pressing the [Continue] button, you will reach the next entry screen.
2. Application
25
26
29
30
34
