SeapiX – Operation Manual
SSD-C-1302 Ed. A – 01/2020 23
4 SeapiX Installation Overview
This chapter gives a brief overview of the SeapiX architecture but does not explain how to
connect the different units together and how to interface with the vessel ancillaries and
servitudes.
For any information about SeapiX system installation, see SeapiX Installation Manual
(can be opened from SeapiX software, ? menu ).
4.1 Architecture and Connections
The simplified architecture of the SeapiX system is as follows:
Simplified SeapiX architecture
* UPS is recommended to protect electronic devices. The UPS model must have a ‘pure sine’ output. Other output
wave forms are not SeapiX compatible.
