SeapiX – Operation Manual
SSD-C-1302 Ed. A – 01/2020 35
Bottom Lock view
It processes near bottom layer with full resolution: the bottom is flattened,
and near bottom fish echoes are more visible.
Omni
Sonar
Example of an omnidirectional sonar view:
This type of view is mostly used by seiners.
Biomass
Example of a biomass view:
See explanation in Biomass menu.
Surface echogram
Bottom Lock
echogram
