SeapiX – Operation Manual
SSD-C-1302 Ed. A – 01/2020 84
Problem
Possible cause
Solution
The Bathymetry display is set to
OFF.
Click the button.
The Acquisition is not selected.
Click the button.
The map is not well centered.
Click the button.
Bathymetry data from SeapiX is
not selected.
Check SeapiX box from
Bathy>Bathy Data menu.
The seabed is too deep.
Verify that the expected depth is
not out of SeapiX specifications.
No biomass data is shown.
Biomass data is not selected.
Click the button.
The selected Biomass swaths
sources are not pinging.
Check the sources of biomass in
Seapix > Settings > Source
The 2D chart is not displaying in
the biomass data location.
Center or zoom out the 2D view in
order to display the Biomass
location.
The filters are not set correctly.
Check the applied filters in the
distribution window accessible by
clicking (TS/SV range,
layers depths)
If you cannot solve the problem, please contact either your SeapiX retailer/dealer or IXblue
Support – Preferably through TeamViewer (see Support through TeamViewer).
