VENTLESS MOUNTING INSTRUCTIONS
INSTALLATION
Locate the wire connectors at the top of the unit and connect the white and black wires from the base unit.
Slide wire into the hole and push the lever down.
Tidy up the wires and lock them in place with the P-Clamp on top of the unit.
P-Clamp
You now have a fully-assembled unit.
6
7
8
