Jackson TempStar Series User Manual

07610-002-23-32-AC
30
PROBLEM POSSIBLE CAUSE REMEDY
Dishmachine lls
slowly and/or rinse is
weak.
Clogged or obstructed rinse arms.
Low incoming water pressure.
Y-strainer is clogged.
Remove and clean the rinse arms.
Adjust the water pressure regulator (not supplied) to ensure the ow
pressure matches the data plate.
Clean out the Y-strainer.
Rinse water is not
reaching required
temperature.
Faulty rinse heater.
Mis-adjusted/faulty thermostat(s).
Rinse thermometer is defective.
Check element for continuity; if open, replace heater.
Verify operation and setting of thermostats; replace if necessary.
Replace thermometer.
Wash water is not
reaching required
temperature.
Faulty wash heater.
Mis-adjusted/faulty thermostat(s).
Wash thermometer is defective.
Check element for continuity; if open, replace heater.
Verify operation and setting of thermostats; replace if necessary.
Replace thermometer.
Doors will not close
completely.
Improper spring tension.
Obstruction in door channel.
Doors are not square with frame.
Adjust spring tension as required by loosening (not removing) spring bolt
nuts and adjusting the tension. Tighten nuts back when done.
Remove the obstruction.
Adjust the frame to accommodate the doors.
Water leaks at the
wash pump.
Wash pump seal defective.
Petcock or pump drain (if
equipped) not shut/tight.
Loose hoses (hose clamps) on the
wash pump.
Replace the seal.
Close or tighten.
Tighten the hose clamps.
Will not rinse during
auto-cycle.
Defective rinse solenoid.
Faulty ll microswitch.
No water to the machine.
Repair or replace the rinse solenoid as required.
Replace microswitch.
Verify that the ow pressure matches the data plate.
Dishes are not
coming clean.
Machine temperatures are not up
to the minimum requirements.
No detergent/too much detergent.
Solid dispenser canister is empty.
Verify that incoming water, rinse water, and wash water match the re-
quired temperatures as listed on the machine data plate.
Adjust detergent concentration as required for the amount of water held
by the machine.
Replace the canister.
COMMON PROBLEMS
TROUBLESHOOTING
WARNING! Inspection, testing, and repair of electrical equipment should only be performed by a
qualied service technician. Many of the tests require that the unit have power to it and live electrical
components be exposed. USE EXTREME CAUTION WHEN TESTING THE MACHINE.
!
WARNING

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
