43
07610-002-23-32-AC
ITEM QTY DESCRIPTION PART NUMBER
1 1 Tub Weldment 05700-002-01-25
2 1 Rack Assembly 05700-002-01-00
3 2 Bulk Head Plug 04730-609-05-00
4 1 Motor Assembly
See "Motor & Pump Assembly"
and "Motors & Heaters” page.
5 1 Gasket 05700-111-35-03
6 1 O-ring 05330-111-35-15
7 4 Bolt, Hex 3/8-16 x 1 1/4" 05305-276-10-00
8 1 Lower Wash Manifold Weldment 05700-031-46-00
9 1 Suction Strain Weldment 05700-002-16-13
10 1 Suction Strain Bracket 05700-002-18-28
11 8 Locknut, 1/4-20 with Nylon Insert 05310-374-02-00
12 1 Strainer Weldment 05700-003-07-76
13 1 Wash Overow Weldment 05700-001-25-69
13a 1 Support, Ball Stop Lift 05700-002-91-55
13b 1 Ball Stop Lift 05700-003-07-50
13c 1 Shim, Overow Support 05700-002-96-48
14 1 Overow Support Bracket 05700-001-27-55
15 1 O-ring 05330-400-05-00
16 2 Clamp, Hose 1 5/16” to 2 1/4” 04730-719-01-37
17 1 Discharge Hose 05700-011-88-24
18 1 Nipple 05700-021-34-84
19 Item intentionally left blank.
20 1 Clamp, Hose 5 5/8" to 6" 04730-011-34-90
21 1 Connector, 1/2” 05975-111-01-00
22 4 Nut, 3/8-16 Hex 05310-276-01-00
23 4 Lockwasher, 3/8” 05311-276-01-00
24 1 See "Motors & Heaters” page. N/A
25 1 Probe, High Water 06680-200-02-68
26 5 Locknut, 6-32 with Nylon Insert 05310-373-03-00
27 4 Lockwasher, 5/16", Split 05311-275-01-00
28 4 Nut, Hex, 5/16-18 05310-275-01-00
29 4 Locknut, 10-24 with Nylon Insert 05310-373-01-00
TUB ASSEMBLY
PARTS
