Jackson TempStar Series User Manual

07610-002-23-32-AC
44
Lockwasher, #8 Internal Tooth 05311-272-03-00
Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
Screw, 8-32 x 3/4" Round Head 05305-172-06-00
Associated Hardware:
ITEM QTY DESCRIPTION PART NUMBER
30 1 Cover, Wash Heater 05700-031-47-57
31 1 Decal, Warning-Disconnect Power 09905-004-08-16
32 1 Decal, Hi-Limit 09905-011-84-32
33 1 Thermostat Bracket 05700-011-81-64
34 1 Wash Heater Gasket 05330-011-47-79
35 1 Thermostat, Regulating 05930-510-02-79
1
Kit, Wash Thermostat Replacement
(
Thermostat, brass tting, two jumper wires, and instructions)
06401-003-18-22
36 1 Thermostat, Hi-limit 05930-011-49-43
37 1 Fitting, 1/4" Imperial Brass 05310-924-02-05
38 1 Probe, Thermistor 4” 06680-004-17-26
39 1 Thermostat Mounting Bracket 05700-004-22-17
40 1 Thermostat, Elan Electric Dual 06685-004-17-27
41 1 Harness, 5-Connector 05700-004-23-78
42 1 Harness, 4-Connector 05700-004-23-79
43 1 Harness, 2-Connector 05700-004-23-80
TUB ASSEMBLY
PARTS

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
