4 CONTROLS
en-25
4.2.20 WEIGHT TRANSFER BUTTON ______________________________________________
The button will transfer weight by the hydraulic system between the drive wheels
and the cutter deck.
To adjust the amount of weight transfer manually on the lift valve. See section 7.2.
4.2.21 HORN __________________________________________________________________
The horn button is on the control panel. If the lighting kit is fitted, the horn is also found on
the end of the indicator stalk (Section 4.8).
4.2.22 POWER OUTLET _________________________________________________________
The Auxiliary Power Outlet is on the control panel next to the ignition switch. It is for use with
mobile phone chargers and accessories.
Automotive 12 Volt, 10-Amp Power Outlet
4.2.23 VISUAL DISPLAY _________________________________________________________
The visual display is activated when the ignition is turned on.
4.2.23.1 STARTUP SCREEN______________________________________________________
When the ignition key is turned to the start position, this screen is shown.
The hour meter will show total hours of engine operation.
