4 CONTROLS
en-37
4.2.23.32 INFORMATION SCREEN TWO ____________________________________________
This screen displays, engine-total fuel used (liter) engine fuel rate (l/h).
Press the button up and down to move between screen one and two.
SETTINGS MENU
Please note some functions require a PIN to access.
4.2.23.33 MODE MENU __________________________________________________________
Select the mode and accept
4.2.23.34 AUTOMATIC / MANUAL / CREEP MODE SELECTION_________________________
Press the button up and down to move between modes.
Automatic (A), Manual (M) and Creep.
Note. The mode selection can only be changed when the machine is stopped.
Select the required mode
and accept
Press the button to return to previous menu.
1. Manual Mode - Works as a conventional mechanical over hydraulic drive
system
2. Auto Mode - Automatic drive features enabled
• Climb assist - Load sensing system adjusts ground speed for efficient
slope climbing
• Cut assist - Load sensing system adjusts ground speed to maintain optimum cutting performance
• Auto Idle -Throttle drops to idle when pedal returns to neutral during transport operations
3. Creep Mode - Cutting system disabled and max speed limited to 8kph (5mph) for safe, controlled use in
workshops, storage facilities and when loading onto vehicles
%
litre
l/h
Engine Total Fuel used
Engine Fuel Rate
DSF Soot
25
5.3
Drive Engine Torque
%
60
Settings Menu
Mode
Measure Units
PIN
MODE Setting
Automatic (A)
Manual (M)
Creep
To Next Page
