CONTROLS 4
en-36
4.2.23.29 SERVICE MANAGER PIN INPUT __________________________________________
Press the button up and down to change the numbers.
Select . to accept.
Initial PIN number is 1001
Note. Service managers are advise to change the pin to stop the machine
parameters being changed to an dangerous condition.
4.2.23.30 ECU MONITOR INFORMATION (J1939) _____________________________________
Select the ECU monitor information and accept .
4.2.23.31 INFORMATION SCREEN ONE ____________________________________________
This screens displays, engine speed (rpm), engine throttle position (%), engine
coolant temperature (°C) and battery voltage (Volt).
Press the button up and down to move between screen one and two.
J1939 Menu
J1939 Information
°C
Volt
rpm
%
Engine Speed
Engine Throttle Position
Engine Coolant Temp
Battery Voltage
2000
65
80
11.8
To Next Page
