6 ADJUSTMENTS
en-69
6.10.5 ARMRESTS ADJUSTMENT (OPTION) ________________________________________
The inclination of the armrests can be modified by turning the adjustment knob
(arrow).
6.10.6 ARMREST (OPTION) ______________________________________________________
The armrests can be folded up if required and the height individually adjusted.
To adjust the armrests for height, separate the round cap (see arrow) from the
cover, loosen the hexagon nut (size 13mm) and adjust the armrest to the desired
position and tighten the nut again.
6.10.7 BACKREST ADJUSTMENT (OPTION) ________________________________________
The backrest extension can be individually adjusted for height by pulling it
upwards over the various increments up to the end stop.
To remove the backrest extension, pull it over the end stop.
6.10.8 LUMBER SUPPORT (OPTION) ______________________________________________
By turning the adjustment knob (arrow) to the left or right, both the height and
curvature of the backrest cushion can be individually adjusted.
This increases both the seating comfort and the performance of the driver.
