ADJUSTMENTS 6
en-70
6.10.9 BACKREST ADJUSTMENT (OPTION)_________________________________________
The backrest is adjusted using the locking lever (arrow).
• The locking lever must latch into the desired position. It should not be
possible to move the backrest into another position when it is locked.
6.10.10 FORE / AFT ISOLATOR (OPTION)___________________________________________
Under certain driving conditions (for example with a trailer attached), it is useful to
activate the fore/aft isolator. This means that shock impacts in the driving direction
can be better absorbed by the driver seat.
Position 1 = fore/aft isolator off
Position 2 = fore/aft isolator on
6.10.11 FORE / AFT ADJUSTMENT (OPTION)________________________________________
The fore/aft adjustment is released by lifting the locking lever.
• The locking lever must latch into the desired position. It should not be
possible to move the driver seat into another position when it is locked.
6.10.12 MULTIFUNCTION ARMREST (OPTION) ______________________________________
After releasing the hand wheel (arrow), the operator can adjust the armrest
vertical and longitudinal direction; the armrest inclination can be adjusted as well.
The vertical and longitudinal adjustment are effected at the same time in
perceptible steps.
• After adjustment has been terminated, tighten the hand-wheel safely
