Janson Controls FC100 Series User Manual

15
3.1 Basic Wiring Diagram
Users must connect wiring according to the circuit diagram shown below. Please follow all
National and State wiring codes, when wiring the FC100.
RS-485
6 1
RA
RC
120VAC/28VDC 3A
0 10VDC
VR 3K 5K
AVI
GND
+10V 10mA(MAX)
3
2
1
VR
RJ-11
1:+EV
2:GND
3:SG-
4:SG+
+18V
+18V
+18V
S1
GND
+18V
4.7K
S2
4.7K
4.7K
4.7K
Factory default settings
Forward/Stop
Reverse/Stop
Reset
Multi-step 1
Common Signal
Power supply for Potentiometer
Master Freq. setting
Analog voltage
Analog current
Motor
Multi-function indication
output contacts
Factory default:
Fault Indication
Main circuit (power)
terminals
Control circuit terminals
Shielded leads
*
NOTE: Do not plug in a Modem or telephone line to the RS-485 communication port,
permanent damage may result. Terminals 1 & 2 are the power source for the
optional copy keypad and should not be used while using RS-485
communication.
Main Circuit Power
Communication
port
+10V
3
FC100 Series User Manaul
Chapter 3 Wire diagram and terminal explanation
