Janson Controls FC100 Series User Manual

8
1
1.5Specifications
V
oltage Class
230V
Model Number FC100
A
0.4
pplicable Motor Output (kW)
0.7 1.5
Rated Frequency (Hz) 1.0~400Hz
Input voltage Tolerance
Single / 3-phase
180~264V 50/60Hz
Power
Frequency tolerance
±
5%
Control system
SVPWM (Sinusoidal Pulse Width Modulation, carried frequency
3kHz~10kHz)
Output Frequency Resolution 0.1Hz
Torque Characteristics
Including the auto-torque, auto-slip compensation, starting torque can be
150% at 5 Hz
Overload Endurance 150% of rated current for 1 minute
Accel/Decel Time 0.1~600Sec. (can be set individually)
V/F pattern V/F pattern adjustable
Control Characteristics
Stall Prevention Level 20~200%, setting of Rated Current
Keypad
Setting by
Frequency
Setting
External Signal
Potentiometer-5K
Ω
/0.5W, DC 0 ~ +10V (input impedance 100K
Ω
), 4~20mA
(
output impedance 250
Ω
), multi-function inputs1 to 3 (3steps, JOG,
UP/DOWN command), communication setting
Operation
Setting
Keypad Setting by RUN//STOP keys
Signal External Signal
FWD,REV,S1,S2 can be combined to offer various modes of operation,
RS-485 communication port
Multi-function Input Signal
Multi-step selection 0 to 3, Jog, accel/decel inhibit, first/second accel/dece
l
switch, counter, PLC Operation, external Base Block (NC,NO) selection
Operating Characteristics
Multi-function Output Signal
AC Drive Operating, Frequency Attained, Non-zero speed, Base Block,
Fault Indication, Local/Remote indication, PLC Operation indication.
Other Function
AVR, S-curve, Over-Voltage Stall Prevention, DC Braking, Fault Records
,
Adjustable Carried Frequency, Starting Frequency Setting of DC Braking ,
Over-Current Stall Prevention, Momentary Power Loss restart, Reverse
Inhibition, Frequency Limits, Parameter Lock/Reset
Protection
Over Voltage, Over Current, Under Voltage, Overload, Electronic thermal,
Overheating, Self-testing
Other Including EMI Filter
Cooling Forced air-cooling
Installation Location Altitude 1,000 m or below, keep from corrosive gasses, liquid and dust
Ambient Temperature
-10 -40 (Non-Condensing and not frozen)
Storage Temperature
-20 to 60
Ambient Humidity Below 90%RH (non-condensing)
Environment
Vibration 9.80665m/s
2
(1G) less than 20Hz, 5.88m/s
2
(0.6Gat) 20 to 50Hz
2.2
FC100 Series User ManualChapter 1 Product Information
