Janson Controls FC100 Series User Manual

71
Group P4: Secondary Application Group
Default value 5.0
Jog frequency setting
P400
Setting Range:0~Max Frequency Unit:0.1
Jog frequency setting is usually applied to trial run. This function can only
be through external terminal.
When JOG function is achieved, other instruction is invalid. When JOG
signal is open, inverter decelerate to stop, JOG acceleration/ deceleration
time is set in the 4th acceleration/ deceleration parameter.
Control priority level:
Jog-External Multi Speed - PLC Operation Means-PID Means - Raingle
Wave(traverse function) - Winding - Frequency Conversion Setting Means
Default value10
Acceleration Time 2
P401
Default value10
Acceleration Time 2
P402
Default value20
Acceleration Time 3
P403
Default value20
Acceleration Time 3
P404
Default value2.0
Acceleration Time 4
P405
Default value2.0
Acceleration Time 4
P406
Setting Range:0~999.9S Unit:0.1
FC100 series inverters can set 4 acceleration / deceleration time. For normal
operation, the default selection is the acceleration / deceleration time 1. For
JOG operation, the default selection is acceleration / deceleration time 4.
Default value100
Setting value of counter
P407
Default value 50
Middle value of counter
P408
Setting Range:0~999.9S Unit.1
Fc100 Series inverter design 2 group of counters, pulase signal less than 250Hz
can be accepted through multi-function terminal, when exeunt value reaches
setting value, corresponding multifunction output terminal is ON, input terminal
of counter resets signal through counter, counter resets and begins counting
again.
Default value 150
Acceleration torque limiting level
P409
Setting Range:0~200 Unit.1
Chapter 6 Description of parameter setting
FC100 Series User Manaul
