1.3FC100SeriesACDrive
ACDriveModel
PowerCapacity
(KVA)
1.5
RatedInput
Current(A)
RatedOutput
Current(A)
AdaptableMotor
(KW)
8.2 0.75
4.7
Input voltage: single-phase 220V Range：-15%~20%
3.0
4.0
14.0
7.5
1.5
23.0 10.0
2.2
FC100-2S-0.7G
FC100-2S-1.5G
FC100-2S-2.2G
Input voltage: three-phase 380V Range: -15%~20%
1.5 3.4 0.752.3
3.0
4.0
5.0 3.7 1.5
5.8 5.1
2.2
FC100-4T-0.7G
FC100-4T-1.5G
FC100-4T-2.2G
5.9 10.5 8.5 4.0
FC100-4T-4.0G
1.4SizeandDimensions
Unit: mm (inches)
