62
Parameter: P33=4 AVI minimum current input P304=20 AVI
maximum current input P310=100.00 analogue low-end frequency
P311=0 analogue low-end direction (Forward)
P312=0 analogue high-end frequency P314=0 analogue high-end
direction (Forward)
Special inverted curve can be constituted by using P310-P314. Introduction:
signal input below 4mA is regarded as invalid signal by inverter.
Default value 6
Multifunction input terminal FWD te
rminal
—
REV terminal
S1 terminal
S2 terminal
P315
Default value 7
Multifunction input terminal
—
P316
Default value 18
Multifunction input terminal
—
P317
Default value 19
Multifunction input terminal
—
P316
Setting Range:0~32 Unit:1
0: Invalid
1： Jog
2: Jog Forward 3: Jog reverse 4:
Forward/ reverse 5: Running 6:
Forward 7: Reverse 8: Stop
9: Multi-speed selection 1
10: Multi-speed selection 2
11: Multi-speed selection 3
12: Multi-speed selection 4
13: Acceleration/ deceleration selection 1
14: Acceleration/ deceleration selection 2
15: Frequency increasing signal Up
16: Frequency decreasing signal Down
17: Coasting stop
18: Fault reset
19: PID function enable
20: PLC function enable
21: Timer 1 start up
22: Timer 2 start up
23: Counter pulse input
24: Counter reset
25: PLC memory clear
26: Winding operation start
Setting
List
6
Chapter 6 Description of parameter setting
FC100 Series User Manaul
